Product Details
| Technical data | W2600E | |
| Battery Type | Maintenance-free lead-acid battery |
Lithium iron phosphate battery |
| Battery capacity/kWh | 19.2 | 28.8 |
| Drive motor/kW | 30 | 30 |
| Pump motor/kW | 28 | 28 |
| Charging voltage/N | 110/220 | 110/220(380) |
| Charging time/h | 6~8 | 6~8(2) |
| Operating voltage V | 12 | |
| Battery Ah | 45 | |
| Operating weight kg | 2600 | |
| Tipping load， max kg | 1500 | |
| Lifting capacity， max kg | 1200 | |
| Operator’scab | Cabin | |
| Travel speed km/h | 0~20 | |
| Steering angle° | 45 | |
| Turn radius inside/outside mm | 1410/3025 | |
| Standard tires | 10.0/75-15.3 | |
| Hydraulic oil tank capacity 1 | 50 | |
| Working hydraulic flow l/min | 43 | |
| Working hydraulic pressure bar | 160 | |
| Transmission type | Electric direct drive | |
