Specifications
| 机器型号 | Model | GAW45 |
| 额定载重 | Operating load (kg) | 700 |
| 最大行驶速度 | Max Speed（km/h） | 10 |
| 液压流量 | Rated flux (L/min) | 80 |
| 轮胎型号 | Tire（track） model | 10-16.5NHS |
| 额定功率 | Rated power (Kw) | 36.7KW |
| 燃油箱容量 | Fuel tank capacity (L) | 70 |
| 自重 | dead weight (kg) | 2916 |
| 操作重量 | self weight bucket (kg) | 3766 |
| 铲斗容积 | Bucket capacity (m³) | 0.4 |
| A. 最大操作高度 | Overall operating height (mm) | 3560 |
| B. 铲斗销高度 | Height to bucket hinge pin (mm) | 2765 |
| C. 驾驶室顶高度（含空调） | Hheight to top of cab (mm) | 2230 |
| D. 铲斗知其底部的最大高度 | Height to bottom of level bucket(mm) | 2909 |
| E. 不带铲斗总长 | Without bucket length（mm） | 2325 |
| F. 带铲斗总长 | Overall length with bucket(mm) | 3276 |
| G. 最大高度卸载角度 | Dumping angle at maximum height(° ) | 37.5 |
| H. 卸料高度 | Dumping height(mm) | 2342 |
| I. 卸载距离 | Dumping reach(mm) | 550 |
| J. 铲斗在地面的反转角度 | Rollback o bucket on ground(° ) | 20.5 |
| K. 铲斗在最高时翻转角度 | Rollback of bucket at full height(° ) | 96.5 |
| L. 轴距 | Wheelbase(mm) | 991 |
| M. 离地间隙 | Ground clearance(mm) | 185 |
| N. 离去角 | Angle of departure(° ) | 20 |
| O. 不带铲斗时转弯半径 | Front turning radius without bucket(mm) | 1188 |
| P. 前转弯半径 | Front tuning radius(mm) | 2030 |
| Q. 后转弯半径 | Rear tuning radius(mm) | 1630 |
| R. 尾部长度 | Rear axle to bumper (mm) | 929 |
| S. 轮距（标准轮胎） | Tread width (mm) | 1462.5 |
| T. 车宽（标准轮胎） | Width (mm) | 1726.5 |
| U. 带标准铲斗宽度 | Bucket width (mm) | 1727 |
