Product Model	GJP50-200
Control Length	200 m
Pipe Diameter	50 mm (2 inch)
Thickness	4.6-4.9 mm
Nozzle Size	10-14 mm
Working Pressure	0.3-0.6 MPa
Recycling Speed	5-25 m/h
Flow	10-25 m³/h
Return Pipe Method	Water turbine / motor return pipe
Spray Range	25-50 m
Spray Nozzle Wheelbase	1.3-1.42 m
Matched Deep Water Pump Power	5.5 kW-7.5 kW
Matched Deep Water Pump Head	50-70 m
Spray Gun Model	30 spray guns
Overall Dimensions	2100 × 1650 × 1550 mm
Whole Machine Weight	350 kg
