Specifications
| 参数项 | 参数值 |
|---|---|
| Model 型号 | GMR-110 |
| LWH 尺寸 (mm) | 21008301475 |
| Maximum Power 最大功率 (kw) | 18 |
| Electric motor type 电动机类型 | Brushless Direct Current Motor 直流无刷电机 |
| Control type 控制类型 | SmartRemote, portable 智能遥控器，便携式 |
| Range, Radio 遥控距离 (m) | 300 |
| Motor Speed 电机转速 (rpm) | 2200 |
| Hydraulic Flow 液压流量 (L/min) | 54 |
| Working oil volume 工作油量 (L/min) | 20-40 |
| System Pressure 系统压力 (MPa) | 18 |
| Charging Voltage 充电电压 (V) | 380-440 |
| Weight Of The Machine 机器重量 (kg) | 1200 |
| Maximum Crushing Height 最大破碎高度 (mm) | 4140 |
| Maximum Crushing Distance 最大破碎距离 (mm) | 3300 |
| Hammer Model 破碎锤型号 | 45 |
| Strike Frequency 冲击频率 (Bpm) | 750-2300 |
| Working Pressure 工作压力 (Bar) | 100-150 |
| Climbing Inclination, max. 最大爬坡倾斜度 (°) | 30 |
| Slewing Speed 回转速度 | 10 sec/360° |
| Signal Code 传输信号 | 2.4G |
| Transport Speed, Max 行走速度 (km/h) | 4.3 |
| Working Mode 工作模式 | Battery Charging 充电 / 插电 |
